General: Low profile lifting beam for minimum head room. The table only shows a few examples of available sizes and provide an indications of dimensions, loads and weights. Other lengths and working loads can be manufactured to suit customer requirements. All beams are supplied complete with shackles according to the table. The beams can be provided with other accessories such as hooks, wire rope slings, chain slings or textile slings. Please also refer to our description in the introduction to this section on lifting beams.
Design: Lightweight welded beam construction providing good torsional stiffness.


Proof: 1,5 x WLL.



  • Material: Beam and plate of high-strength structural steel.
  • Marking: Working load limit and CE marking.
  • Finish: Yellow painted.
  • Note: Also manufactured with plates and/or excavator hooks in the ends.
6600bm_micke_225mm
Select a row from the table below, then click the add to quote button
Art No WLL
Ton
Length (m) CAD
13.356600005 0.5 1-6
13.356600010 1 1-6
13.356600020 2 1-6
13.356600030 3 1-6
13.356600040 4 1-6
13.356600050 5 1-6
13.356600060 6 1-6
13.356600080 8 1-6
13.356600100 10 1-6
13.356600120 12 1-6
13.356600150 15 1-6
13.356600200 20 1-6
13.356600xxx 1-6

* Specified lifting beam lengths are standard lengths, other lengths and loads upon request.
