Quick Link

  • Not for lifting

General: For use to connect or lengthen grade 2 chain.


WARNING! Not for lifting.

  • Finish: Galvanized.
Rz_e_225mm
Rz_e_225mm
Rzm_e_225mm
Select a row from the table below, then click the add to quote button
Part Code Code Diameter
mm		 A
mm		 C
mm		 L
mm		 D
mm		 Weight
kg/100pc		 CAD
11.56QL035 RZ-3,5 3.5 10 5 29 3,5 1.2
11.56QL040 RZ-4 4 11 5 31 4 2.1
11.56QL050 RZ-5 5 13 6 38 5 2.2
11.56QL060 RZ-6 6 14 7 45 6 3.6
11.56QL070 RZ-7 7 16 8 52 7 5
11.56QL080 RZ-8 8 18 10 60 8 7.8
11.56QL090 RZ-9 9 19 11 64 9 10
11.56QL100 RZ-10 10 20 12 69 10 14
11.56QL120 RZ-12 12 25 15 83 12 20

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.

Get CAD
Download
