Kito

Electric chain hoist with hook suspension

General:
The KITO ER2 Electric Chain Hoists are durable, safe and easy to use hoists. It has a top hook or overhead mounting suspension, aluminium die-cast body, electromagnetic brake and a canvas chain container.
It lifts from 125 kg up to 5 tons.

Standard configuration:

  • 400 V/50 Hz
  • Frequency inverter for 2 lifting speeds
  • CH-Meter: operating hours/number of starts
  • Ergonomic push button control
  • Upper-lower limit switch
  • Nickel-plated load chain class grade 80 (DAT) in accordance with Norm EN 818-7
  • Thermal protector
  • Carbon friction clutch


Options:

  • 500 V/Contactor control
  • 230 V/50 Hz/60 Hz, 3 phase
  • Rubber bumpers for motorized trolleys
  • Additional mechanical brake
  • Electrical overload limiter
  • Acoustic overload signal
  • Radio remote control
  • Variable speed control
  • Level limit switch
  • Steel chain container
  • Trolley versions: motorized, geared and plain
  • Note: Can also be delivered with infinitely variable speed control, programmable level limits and cylinder control.
ER2025
ER2 cylinder control
ER2 Single_CE
Select a row from the table below, then click the add to quote button
WLL
Ton
Product code Load chain Ø (mm) Chain falls Lifting motor Output (kW) Lifting motor Rating (%ED) Class ISO/FEM Additional weight per 1 m lift Lifting speed*(m/min) 50Hz high Lifting speed*(m/min) 50Hz low Test load kg Weight
kg
CAD
0.125 ER2-001IH 4,3 x 12 1 0,56 40/20 M6/3m 0.42 16,6 2,81,4 156 27
0.25 ER2-003IS 4,3 x 12 1 0,56 40/20 M6/3m 0.42 10,8 1,80,9 313 27
0.25 ER2-003IH 6,0 x 16,8 1 0,9 40/20 M6/3m 0.81 15,7 2,61,3 313 36
0.5 ER2-005IL 6,0 x 16,8 1 0,56 40/20 M6/3m 0.81 4,5 0,80,4 625 32
0.5 ER2-005IS 6,0 x 16,8 1 0,9 40/20 M6/3m 0.81 8,5 1,40,7 625 36
1 ER2-010IL 7,7 x 21,5 1 0,9 40/20 M5/2m 1.33 4,2 0,70,3 1,250 45
1 ER2-010IS 7,7 x 21,5 1 1,8 40/20 M5/2m 1.33 8,2 1,40,7 1,250 52
1.6 ER2-016IS 10,2 x 28,5 1 1,8 40/20 M5/2m 2.3 5,3 0,90,4 2,000 72
2 ER2-020IL 10,2 x 28,5 1 1,8 40/20 M4/1Am 2.3 4,3 0,70,4 2,500 73
2 ER2-020IS 10,2 x 28,5 1 3,5 40/20 M4/1Am 2.3 8,2 1,40,7 2,500 89
2.5 ER2-025IS 11,2 x 31,3 1 3,5 40/20 M4/1Am 2.8 6,6 1,10,6 3,130 100
3.2 ER2-032IS 10,2 x 28,5 2 3,5 40/20 M4/1Am 4.7 5,2 0,90,4 4,000 105
5 ER2-050IS 11,2 x 31,3 2 3,5 40/20 M4/1Am 5.6 3,3 0,60,3 6,250 128
* Note: The high speed is present to the maximum speed at the KITO factory in Japan. The low speed can be increased or respectively reduced.

Lifting speed - Preset/Adjustable

Download CAD

Description

Get CAD
Download

Dimensions

WLL
Product
Min. headroom C
D
a
b
d
e
f
g
h
i
tons
code
mm
mm
mm
mm
mm
mm
mm
mm
mm
mm
0,125
ER2-001IH
350
430
535
345
276
259
284
27
99
117
0,250
ER2-003IS
350
430
535
345
276
259
284
27
99
117
0,250
ER2-003IH
370
490
568
348
300
268
283
27
113
106
0,5
ER2-005IL
370
490
571
348
300
271
283
27
113
106
0,5
ER2-005IS
370
490
568
348
300
268
283
27
113
106
1
ER2-010IL
430
550
614
376
316
298
335
31
129
118
1
ER2-010IS
430
550
623
376
316
307
335
31
129
118
1,6
ER2-016IS
510
630
710
427
372
338
384,5
34
160,5
137,5
2
ER2-020IL
575
630
710
427
372
338
384,5
39
160,5
137,5
2
ER2-020IS
590
630
767
427
411
356
384,5
39
160,5
137,5
2,5
ER2-025IS
625
840
800
445
401
399
437,5
39
173,5
142,5
3,2
ER2-032IS
785
920
767
427
411
356
397
44
216
82
5
ER2-050IS
850
920
800
445
401
399
439
47
231,5
84,5
