General: For handling of standard pallets from the long side.
Design: Thanks to the spring-loaded lifting eye, the pallet fork is self-balancing, which means that the forks are always horizontal, regardless of whether the pallet fork is empty or loaded. Please note the minimum load specified in the table. Concealed spring and linkage.
Proof: Batch proof 1,5 x max load.

  • Material: Beam and plate of high-strength structural steel.
  • Marking: Minimum load, maximum load and CE-marking.
  • Finish: Yellow painted.
  • Note: :Other sizes and designs are available upon request. For custom made forks the type has some restrictions regarding small loads and low profile goods (measure H).
6020-23m_new_225mm
Select a row from the table below, then click the add to quote button
Art No Code WLL
Ton
A (mm) E (mm) H (mm) L (mm) S (mm) Min load kg Tp max* Weight
kg
CAD
13.306022F 6022-F 1.5 700 980 1,500 485 50 300 500 86
13.306020F 6020-F 2 700 800 1,500 485 50 300 400 80
13.306023F 6023-F 2.5 700 980 1,500 515 60 300 500 100
13.306021F 6021-F 3 700 800 1,500 515 60 300 400 92

*The "Tp max" value is valid for maximum load. The pallet forks can be used with a greater point of balance if the load is reduced.
