General: Chain for different applications.

Standard: Dimesion acc. to DIN 763.

  • Material: AISI 316.
  • Warning: Not for lifting.
  • Grade: 2
Hlrx_225mm
HLM_e_225mm HLM_e_225mm
Select a row from the table below, then click the add to quote button
Part Code Diameter
mm
Length (m) E (mm) H (mm) Weight
kg/m
CAD
11.60763020SR50 2 50 22 4 0.06
11.60763030SR50 3 50 26 8 0.15
11.60763040SR50 4 50 32 8 0.27
11.60763050SR30 5 30 35 10 0.43
11.60763060SR30 6 30 42 12 0.63
11.60763080SR15 8 15 54 16 1.1
11.60763100SR15 10 15 66 20 1.8
*Please note that this product is sold only in rolls.
