General: For small or medium-sized loads and moderate coil widths. See the introductory text above in the section on C-hooks.
Design: Hollow beam that is lighter in weight than equivalent steel plate. The counterbalance ensures that the fork is always in a horizontal position, regardless of whether the hook is empty or loaded.
Proof: 1,5 x WLL.
- Material: Hollow-beam of high-strength structural steel.
- Marking: Type, working load limit, maximum coil width and CE marking.
- Finish: Yellow painted.
- Note: We recommend the use a of 2-leg chain sling, headroom permitting as an increase in dimension L provides better balance.
- Safety factor: 1,5 x WLL.
Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
