Ropeblock

General: Intended for attaching of wire rope where switching often occur, e.g. blocks of mobilecranes, or to be able to adjust the length of the wire rope. See recommended assembly to get correct results.
Design: The wedge socket is delivered complete.

Marking house and wedge: Wire ø mm.



The dead end should have a length of 6 times the wire dia. with a minimum of 150mm.

  • Material: Cast alloy steel with high mechanical properties.
  • Finish: Blue painted or hot dip galvanized (OWS 0.25 to 0.5 is standard delivered with galvanized finish) / Pin or bolt.
  • Note: The efficiency of a 6 and 8 strand wire rope/wedge socket connection is 80% of the minimum breaking load of the wire but limited to the minimum breaking load of the socket (MBL).
OWS 3 P
wedge_socket_225mm
Select a row from the table below, then click the add to quote button
Part Code Code MBL
ton
Rope Ø (mm) Finish TB (mm) TL (mm) A (mm) B (mm) C (mm) Ø P (mm) T (mm) W (mm) Weight
kg
CAD
10.20OWS0025PGAL OWS 0,25 P 8 7-8 G 51 128 110 18 36 16 9 18 0.8
10.20OWS005PGAL OWS 0,5 P 12 9-10 G 63 165 145 23 46 21 11 21 1.7
10.20OWS01PGAL OWS 1 P 20 11-13 G 67 174,5 146 28,5 57 25 12 25 2.1
10.20OWS02PGAL OWS 2 P 25 14-16 G 85 211 176 35 70 30 15 31 4
10.20OWS03PGAL OWS 3 P 40 18-19 G 95 250 210 40 80 35 16 38 7
10.20OWS04PGAL OWS 4 P 55 20-22 G 110 285 237,5 47,5 95 41 18 44 10
10.20OWS05PGAL OWS 5 P 75 24-26 G 128 330 275 55 110 51 22 51 15
10.20OWS06PGAL OWS 6 P 90 27-29 G 142 375 310 65 130 57 25 57 21
10.20OWS07PGAL OWS 7 P 110 30-32 G 155 423 350 73 146 64 28 63 31
10.20OWS08PGAL OWS 8 P 125 34-36 G 160 474 400 74 148 64 28 70 37
10.20OWS09PGAL OWS 9 P 150 37-39 G 177 530 450 80 142 70 30 77 51
10.20OWS10PGAL OWS 10 P 170 40-42 G 187 587 500 87 160 76 33 76 64
10.20OWS11PGAL OWS 11 P 225 43-48 G 215 650 550 100 186 89 39 89 96

Code: OWS xx P - Pin , OWS xx B - Bolt

Finish: P-Painted, G-Galvanized
