Casar
  • Ordinary right hand lay
  • Ordinary left hand lay
  • Bright
  • Galvanized
  • Compacted strands
  • Double parallel lay construction
  • Swaged
  • Not to be used with swivel

Advantages and features:
- Extremely high breaking strength
- Very stabile wire rope construction with good fatigue properties
- A plastic layer between inner and outer strands prevents inner wear and protects the core from corrosion.
- Very high resistance against flattening and wear.
- Especially suitable for multiple layer spooling.
ISO 4309 Rope Category No: 8-50mm RCN.09,

  • Rope construction: 8 strand hammered rope in parallel lay construction made out of compacted outer strands. Has a plastic layer between the steel core and the outer strands, giving the rope a high structural s
  • Standard: EN 12385-4
  • Fill factor: 0.74
  • Offshore crane
  • Crawler crane
Parafit[new]_225mm
Parafit
Offshore crane
Select a row from the table below, then click the add to quote button
Art No Diameter
mm
Steel Area
mm²
Min. breakingforce
kN
1960 N/mm²
Min. breakingforce
kN
2160 N/mm²
Weight
kg/100m
01.B13---080G 8 37 63.1 68.7 29
01.B13---090G 9 46.6 79.4 86.5 37
01.B13---100G 10 57.1 97.3 106 49
01.B13---110G 11 71.2 121 132 55
01.B13---120G 12 82.7 141 154 65
01.B13---130G 13 97.9 167 182 77
01.B13---140G 14 115 196 213 89
01.B13---150G 15 131 223 243 102
01.B13---160G 16 150 255 278 117
01.B13---170G 17 171 292 318 132
01.B13---180G 18 189 323 352 146
01.B13---190G 19 214 364 397 163
01.B13---200G 20 234 398 434 181
01.B13---210G 21 257 437 477 198
01.B13---220G 22 285 485 529 220
01.B13---230G 23 310 528 576 240
01.B13---240G 24 338 576 628 261
01.B13---250G 25 366 624 680 282
01.B13---260G 26 394 672 732 307
01.B13---280G 28 459 783 853 353
01.B13---300G 30 529 902 983 410
01.B13---320G 32 598 1,019 1,110 464
01.B13---340G 34 679 1,157 1,261 523
01.B13---360G 36 758 1,292 1,407 583
01.B13---380G 38 848 1,446 1,576 655
01.B13---400G 40 935 1,594 1,736 729
Other dimensions and tensile grade on request.
