• Material: Alloy steel grade 8.
  • Marking: Code and grade.
  • Finish: Painted.
  • Warning: Not to be heat-treated.
  • Safety factor: 4:1.
  • Grade: 8
MLA
MLAm_225mm
Select a row from the table below, then click the add to quote button
Art No Code WLL
Ton
B (mm) D (mm) L (mm) b (mm) d (mm) l (mm) Weight
kg
CAD
11.01A360J MLA-5-8 2 60 16 110 60 16 110 1.6
04.02MLA07 MLA-7-8 3.15 75 18 135 75 18 135 2
11.01A362J MLA-8-8 5.3 90 22 160 90 22 160 3.2
11.01A363J MLA-10-8 8 100 26 180 100 26 180 5.3
11.01A365J/1 MLA-13-8 12.5 140 36 260 140 36 260 14
04.02MLA14 MLA-14-8 15 160 40 300 160 40 300 22
04.02MLA16 MLA-16-8 22 180 45 340 180 45 340 39
04.02MLA22 MLA-22-8 32 190 50 350 190 50 350 42
04.02MLA23 MLA-23-8 35 200 56 400 200 56 400 70
Other dimensions on request.
MLAC - Small size sub-links (especially suitable for chain slings with 3-4 legs)
