WARNING! Not to be heat-treated.

  • Material: Alloy steel grade 8.
  • Marking: Code and grade.
  • Finish: Painted
  • Safety factor: 4:1.
  • Grade: 8
FH_new_225mm_2_[2]
FHm_new4_225mm
Select a row from the table below, then click the add to quote button
Art No Code WLL
Ton
D (mm) C (mm) L (mm) T (mm) k (mm) Weight
kg
04.57FH06 FH-6-8 1.12 50 10 95 15 24 0.6
04.57FH16 FH-16-8 8 102 24 207 35 50 5.3
04.57FH20 FH-18/20-8 12.5 114 26 235 40 67 11
04.57FH22 FH-22-8 15 127 30 265 47 70 13
04.57FH26 FH-24/26-8 21.2 136 34 305 54 80 18
04.57FH32 FH-32-8 31.5 152 40 327 60 100 27
11.10B701J FH-7/8-8 2 64 14,5 136 28,5 36 1.1
11.10B702J FH-10-8 3.15 78 18 166 36,1 44 2.1
11.10B703J FH-13-8 5.3 89 20 190 41 51 3.5
