General: Sheave block, double-spindled

  • Material: Spindle made from nylon. Frame cast alloy.
Sheave_double
Sheave_double_measure
Select a row from the table below, then click the add to quote button
Art No Diameter
mm
D2 (mm) d1 (mm) L (mm) CAD
02.69PYLKK5 5 15 10 50
02.69PYLKK6 6 20 11 60
02.69PYLKK7 7 25 12 70
02.69PYLKK8 8 30 13 80
02.69PYLKK9 9 40 14 93
02.69PYLKK12 12 50 16 117
